TSXDEZ12D2K
کارت TSX MICROO مدل TSXDEZ12D2K
Discrete input module, Modicon TSX Micro, 12 inputs, 2/3 wire proximity sensors PNP/NPN, impedance 3.4ohm
×
![]()
مشخصات کامل
Range of product
Modicon TSX Micro automation platform
Range of product
Product or component type
Discrete input module
Product or component type
Discrete input number
12 1 HE-10 connector
Discrete input number
Discrete input voltage
24 V DC, discrete input logic: positive
19...30 V
19...30 V
Discrete input voltage
Discrete input current
7 mA
Discrete input current
Input voltage limits
>= 11 V at state 1
< 5 V at state 0
< 5 V at state 0
Input voltage limits
Current state 0 guaranteed
<= 2 mA
Current state 0 guaranteed
Current state 1 guaranteed
>= 6 mA
Current state 1 guaranteed
Input impedance
3.4 Ohm
Input impedance
Response time
0.1...7.5 ms at state 0 to state 1
0.1...7.5 ms at state 1 to state 0
0.1...7.5 ms at state 1 to state 0
Response time
Standards
IEC 1131-2 Type 2
Standards
Input compatibility
2/3-wire proximity sensors PNP/NPN
Input compatibility
Discrete input type
Current sink
Discrete input type
Current consumption
104 mA positive
Current consumption
Isolation voltage
1500 V AC 1 s
Isolation voltage
Net weight
0.16 kg
Net weight
Unit Type of Package 1
PCE
Unit Type of Package 1
Number of Units in Package 1
1
Number of Units in Package 1
Package 1 Height
5.5 cm
Package 1 Height
Package 1 Width
18.0 cm
Package 1 Width
Package 1 Length
26.0 cm
Package 1 Length
Package 1 Weight
260.0 g
Package 1 Weight
Warranty
18 months
Warranty
