170DNT11000
کارت پی ال سی اشنایدر آداپتور ارتباطی، پلت فرم اتوماسیون Modicon Momentum، Profibus DP، 9.6 تا 12 مگابیت بر ثانیه، کابل جفت پیچ خورده
Communication adaptor, Modicon Momentum automation platform, Profibus DP, 9.6 to 12Mbit/s, twisted pair cable
×
![]()
مشخصات کامل
Range of product
Modicon Momentum automation platform
Range of product
Product or component type
Profibus DP communication adaptor
Product or component type
communication port protocol
Profibus DP
communication port protocol
Method of access
Master/slave
Method of access
Transmission rate
9.6...12 Mbit/s
Transmission rate
Transmission support medium
Twisted pair
Transmission support medium
Topology
Ring
Multidrop
Multidrop
Topology
Number of devices per segment
0…126
Number of devices per segment
Maximum cable distance between devices
1200 m
Maximum cable distance between devices
Addressing
Switch selectable
Addressing
Fail state
Fail safe
Fail state
Control parameter
CRC-16
Control parameter
Supply
From I/O base
Supply
Marking
CE
Marking
Local signalling
1 LED (green) for bus fault (BF)
Local signalling
Electrical connection
1 connector SUB-D 9
Electrical connection
Module format
Standard
Module format
Net weight
0.07 kg
Net weight
Product certifications
CSA
UL
UL
Product certifications
IP degree of protection
IP20
IP degree of protection
Protective treatment
TC
Protective treatment
Resistance to electrostatic discharge
4 kV contact conforming to IEC 801-2
8 kV on air conforming to IEC 801-2
8 kV on air conforming to IEC 801-2
Resistance to electrostatic discharge
Resistance to electromagnetic fields
10 V/m 80...1000 MHz conforming to IEC 801-3
Resistance to electromagnetic fields
Ambient air temperature for operation
0???60 °C
Ambient air temperature for operation
Ambient air temperature for storage
-40…85 °C
Ambient air temperature for storage
Relative humidity
95 % without condensation
Relative humidity
Operating altitude
<= 5000 m
Operating altitude
Unit Type of Package 1
PCE
Unit Type of Package 1
Number of Units in Package 1
1
Number of Units in Package 1
Package 1 Height
5.5 cm
Package 1 Height
Package 1 Width
17.9 cm
Package 1 Width
Package 1 Length
25.9 cm
Package 1 Length
Package 1 Weight
188.0 g
Package 1 Weight
Warranty
18 months
Warranty
