140CPS52400
منبع تغذیه 125 ولت DC مازاد مدل 140CPS52400
power supply module Modicon Quantum - 125 V DC 100..150 V - redundant - 8 A
×
![]()
مشخصات کامل
Range of Product
Modicon Quantum automation platform
Range of Product
Product or Component Type
Power supply module
Product or Component Type
Power supply type
Redundant
Power supply type
Input voltage
125 V 100...150 V) DC
Input voltage
Input current
500 mA 125 V
Input current
Inrush current
28 A 125 V
Inrush current
Maximum input power interruption
1 ms
Maximum input power interruption
Associated fuse rating
2 A, slow-blow
Associated fuse rating
Output voltage
5.1 V DC
Output voltage
Power supply output current
8 A redundant
Power supply output current
Output overvoltage protection
Internal
Output overvoltage protection
Output overload protection
Internal
Output overload protection
Power dissipation
6 + (1.5 x Iout) where Iout is in A
Power dissipation
Local signalling
for power (PWR OK) 1 LED (green)
Local signalling
Marking
CE
Marking
Module format
Standard
Module format
Net Weight
1.43 lb(US) (0.65 kg)
Net Weight
Standards
CSA C22.2 No 142
UL 508
UL 508
Standards
Product Certifications
FM Class 1 Division 2
cUL
cUL
Product Certifications
Resistance to electrostatic discharge
4 kV contact IEC 801-2
8 kV on air IEC 801-2
8 kV on air IEC 801-2
Resistance to electrostatic discharge
Resistance to electromagnetic fields
9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3
Resistance to electromagnetic fields
Ambient air temperature for operation
32…140 °F (0…60 °C)
Ambient air temperature for operation
Ambient Air Temperature for Storage
-40…185 °F (-40…85 °C)
Ambient Air Temperature for Storage
Relative Humidity
95 % without condensation
Relative Humidity
Operating altitude
<= 16404.2 ft (5000 m)
Operating altitude
Category
US1PC2118155
Category
Discount Schedule
PC21
Discount Schedule
GTIN
3595861137127
GTIN
Returnability
No
Returnability
Country of origin
CN
Country of origin
Unit Type of Package 1
PCE
Unit Type of Package 1
Number of Units in Package 1
1
Number of Units in Package 1
Package 1 Height
1.90 in (4.83 cm)
Package 1 Height
Package 1 Width
6.50 in (16.51 cm)
Package 1 Width
Package 1 Length
12.40 in (31.5 cm)
Package 1 Length
Package 1 Weight
2.006 lb(US) (0.91 kg)
Package 1 Weight
Unit Type of Package 2
S03
Unit Type of Package 2
Number of Units in Package 2
7
Number of Units in Package 2
Package 2 Height
11.81 in (30 cm)
Package 2 Height
Package 2 Width
11.81 in (30 cm)
Package 2 Width
Package 2 Length
15.75 in (40 cm)
Package 2 Length
Package 2 Weight
15.0 lb(US) (6.8 kg)
Package 2 Weight
Warranty
18 months
Warranty
