140CPS42400
منبع تغذیه کوانتومی 48 ولت DC مدل 140CPS42400
power supply module Modicon Quantum - 48..60 V DC - redundant
×
![]()
مشخصات کامل
Range of Product
Modicon Quantum automation platform
Range of Product
Product or Component Type
Power supply module
Product or Component Type
Power supply type
Redundant
Power supply type
Input voltage
48...60 V 48...60 V) DC
Input voltage
Input current
3800 mA
Input current
Inrush current
14 A 40 V
Inrush current
Maximum input power interruption
13 ms 48 V
Maximum input power interruption
Associated fuse rating
2 A, time-lag
Associated fuse rating
Output voltage
5.1 V DC
Output voltage
Power supply output current
8 A redundant
Power supply output current
Output overvoltage protection
Internal
Output overvoltage protection
Output overload protection
Internal
Output overload protection
Power dissipation
17.2 W
Power dissipation
Alarm output
1 NC 6 A 220 V power supply fault
Alarm output
Local signalling
for power (PWR OK) 1 LED (green)
Local signalling
Marking
CE
Marking
Module format
Standard
Module format
Net Weight
1.43 lb(US) (0.65 kg)
Net Weight
Standards
CSA C22.2 No 142
UL 508
UL 508
Standards
Product Certifications
cUL
Product Certifications
Resistance to electrostatic discharge
4 kV contact IEC 801-2
8 kV on air IEC 801-2
8 kV on air IEC 801-2
Resistance to electrostatic discharge
Resistance to electromagnetic fields
9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3
Resistance to electromagnetic fields
Ambient air temperature for operation
32…140 °F (0…60 °C)
Ambient air temperature for operation
Ambient Air Temperature for Storage
-40…185 °F (-40…85 °C)
Ambient Air Temperature for Storage
Relative Humidity
95 % without condensation
Relative Humidity
Operating altitude
<= 16404.2 ft (5000 m)
Operating altitude
Category
US1PC2118155
Category
Discount Schedule
PC21
Discount Schedule
GTIN
3595861000070
GTIN
Returnability
No
Returnability
Country of origin
US
Country of origin
Unit Type of Package 1
PCE
Unit Type of Package 1
Number of Units in Package 1
1
Number of Units in Package 1
Package 1 Height
6.42 in (16.3 cm)
Package 1 Height
Package 1 Width
1.77 in (4.5 cm)
Package 1 Width
Package 1 Length
12.28 in (31.2 cm)
Package 1 Length
Package 1 Weight
29.7 oz (843 g)
Package 1 Weight
Warranty
18 months
Warranty
