140CPS11100
ماژول منبع تغذیه کوانتومی مودیکون 120..230 ولت AC تک دستگاه مدل 140CPS11100
power supply module Modicon Quantum - 120..230 V AC - standalone
×
![]()
مشخصات کامل
Range of Product
Modicon Quantum automation platform
Range of Product
Product or Component Type
Power supply module
Product or Component Type
Power supply type
Standalone
Power supply type
Input voltage
120...230 V 100...276 V) AC 47…63 Hz
Input voltage
Input current
200 mA 230 V
400 mA 115 V
400 mA 115 V
Input current
Inrush current
10 A 230 V
20 A 115 V
20 A 115 V
Inrush current
rated power in VA
50 VA
rated power in VA
Associated fuse rating
1.5 A, slow-blow
Associated fuse rating
Harmonic distortion
<= 10 % of fundamental rms value
Harmonic distortion
Output voltage
5.1 V DC
Output voltage
Power supply output current
3 A standalone
Power supply output current
Output overvoltage protection
Internal
Output overvoltage protection
Output overload protection
Internal
Output overload protection
Power dissipation
2 + (3 x Iout) where Iout is in A
Power dissipation
Local signalling
for power (PWR OK) 1 LED (green)
Local signalling
Marking
CE
Marking
Module format
Standard
Module format
Net Weight
1.43 lb(US) (0.65 kg)
Net Weight
Standards
UL 508
CSA C22.2 No 142
CSA C22.2 No 142
Standards
Product Certifications
cUL
FM Class 1 Division 2
FM Class 1 Division 2
Product Certifications
Resistance to electrostatic discharge
4 kV contact IEC 801-2
8 kV on air IEC 801-2
8 kV on air IEC 801-2
Resistance to electrostatic discharge
Resistance to electromagnetic fields
9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3
Resistance to electromagnetic fields
Ambient air temperature for operation
32…140 °F (0…60 °C)
Ambient air temperature for operation
Ambient Air Temperature for Storage
-40…185 °F (-40…85 °C)
Ambient Air Temperature for Storage
Relative Humidity
95 % without condensation
Relative Humidity
Operating altitude
<= 16404.2 ft (5000 m)
Operating altitude
Category
US1PC2118155
Category
Discount Schedule
PC21
Discount Schedule
GTIN
3595861135208
GTIN
Returnability
No
Returnability
Country of origin
US
Country of origin
Unit Type of Package 1
PCE
Unit Type of Package 1
Number of Units in Package 1
1
Number of Units in Package 1
Package 1 Height
6.42 in (16.3 cm)
Package 1 Height
Package 1 Width
1.77 in (4.5 cm)
Package 1 Width
Package 1 Length
12.28 in (31.2 cm)
Package 1 Length
Package 1 Weight
23.5 oz (665.0 g)
Package 1 Weight
Warranty
18 months
Warranty
