140ACO13000
ماژول خروجی آنالوگ کوانتومی مدیکون، 8 O، ماژول چند بردی مدل 140ACO13000
analog output module Modicon Quantum - 8 O multirange
×
![]()
مشخصات کامل
Range of Product
Modicon Quantum automation platform
Range of Product
Product or Component Type
Analogue output module
Product or Component Type
Analogue output number
8
Analogue output number
Addressing requirement
8 output words
Addressing requirement
Loop voltage
6…30 V DC
Loop voltage
Maximum voltage drop
<30 V 25 mA
Maximum voltage drop
Analogue output range
0...20 mA 0...20000 counts
0...25 mA 0...25000 counts
4...20 mA 0...16000 counts
4...20 mA 0...4095 counts
0...25 mA 0...25000 counts
4...20 mA 0...16000 counts
4...20 mA 0...4095 counts
Analogue output range
Absolute accuracy error
+/- 0.2 % of full scale 77 °F (25 °C)
Absolute accuracy error
Linearity
+/- 12 µA 4...20 mA 0...4095 counts
+/- 4 µA 0...20 mA 0...20000 counts
+/- 4 µA 0...25 mA 0...25000 counts
+/- 4 µA 4...20 mA 0...16000 counts
+/- 4 µA 0...20 mA 0...20000 counts
+/- 4 µA 0...25 mA 0...25000 counts
+/- 4 µA 4...20 mA 0...16000 counts
Linearity
Accuracy drift according to temperature
0.004 % of full scale/°C typical
0.007 % of full scale/°C maximum
0.007 % of full scale/°C maximum
Accuracy drift according to temperature
Isolation between channels and bus
1780 V for 1 minute AC
Isolation between channels and bus
Update time
5 ms
Update time
Setting time
3.2 ms to +/-0.1% of the final value
1.6 ms to 5% of the final value
1.6 ms to 5% of the final value
Setting time
Fault type
Open circuit 4...20 mA
Fault type
Bus current requirement
550 mA
Bus current requirement
Maximum power dissipation in W
5 W
Maximum power dissipation in W
External power requirement
6...30 V
External power requirement
Marking
CE
Marking
Local signalling
for bus communication is present (Active) 1 LED (green)
for external fault 1 LED (red)
for channel is turned on 8 LEDs (green)
for channel fault 8 LEDs (red)
for external fault 1 LED (red)
for channel is turned on 8 LEDs (green)
for channel fault 8 LEDs (red)
Local signalling
Module format
Standard
Module format
Net Weight
0.7 lb(US) (0.3 kg)
Net Weight
Product Certifications
cUL
FM Class 1 Division 2
FM Class 1 Division 2
Product Certifications
Standards
UL 508
CSA C22.2 No 142
CSA C22.2 No 142
Standards
Resistance to electromagnetic fields
9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3
Resistance to electromagnetic fields
Ambient air temperature for operation
32…140 °F (0…60 °C)
Ambient air temperature for operation
Ambient Air Temperature for Storage
-40…185 °F (-40…85 °C)
Ambient Air Temperature for Storage
Relative Humidity
95 % without condensation
Relative Humidity
Operating altitude
<= 16404.2 ft (5000 m)
Operating altitude
Category
US1PC2118155
Category
Discount Schedule
PC21
Discount Schedule
GTIN
3595861148017
GTIN
Returnability
Yes
Returnability
Country of origin
US
Country of origin
Unit Type of Package 1
PCE
Unit Type of Package 1
Number of Units in Package 1
1
Number of Units in Package 1
Package 1 Height
1.89 in (4.800 cm)
Package 1 Height
Package 1 Width
6.57 in (16.700 cm)
Package 1 Width
Package 1 Length
12.40 in (31.500 cm)
Package 1 Length
Package 1 Weight
15.450 oz (438.000 g)
Package 1 Weight
Warranty
18 months
Warranty
